HomeTATA Smart 360^o Wash System

Tata Wash Equipment - TATA Smart 360^o Wash System

The TWE Smart 360* enhances the wash experience with its touch less high-pressure automatic car wash systems. Get the best output to the Business Revenue.

TWE Smart 360* makes the machine responsive to the gigantic conditions in the wash bay and allows the machine to efficiently be robotic to increasing up-time and optimizing the wash process.

Key Features

Intelligent unmanned systems.

Smart 360* technology.

Intelligent liquid mixing system.

Innovative suspension system non-resistance rails.

Unique embedded fast drying system.

Digital voice security alarm system.

Faulty self-checking system.

Automatic collision avoidance technology

One key anti-frozen system

Floor Mounted Trolley
Energy Chain System
Structure Body painted with High Gloss Automotive Paint
Anti-Tilt and Anti Derailing Mechanism
Space Saving Trolley Design
Semi-Assembled System for quick installation
Trolley Speed of 10 - 15 m/min
PLC Controlled Automatic System
Very sensitive Control system for safety of the vehicle
VFD Controlled Drive, Horizontal Brush
High Penetration IP67 Sensors

Touch Screen Operation
Onboard Control Panel
Automatic / Manual Model
Contour Following Top and Vertical Brushes
High Quality PE bristle Brushes
Stainless Steel / PPE Nozzles
Stainless Steel Piping
Soap System
Chemical Dosing Pumps (Supports most chemicals)
Easy to Operate
Easy to Understand and Maintain

Standard parts and components used (available anywhere in the world)
Imported Polyethylene Bristle brushes
Fully Hot Dip Galvanized Interior and Exterior Frame Construction.
In-Build weather proof PLC based Operating Control Panel
Water Proof IP66 motors
Long lasting Aluminum Strut Pipe Brush Rollers
Trafficator Lights for guidance & machine safety
Stainless Steel Water Nozzles
High Quality Polycarbonate Splash Guard for effective body protection from water splashes during washing cycle.

Entry Point Under Chassis Wash Equipment
TWE 2BT Equipment Height Extension up-to (4.1m, 4.6m, 5.1m)
Exit Side Blowers 30 HP

Truck Wash Side Blasters
Backlight Wash Cycle Display
3 years Spares kit

LED Bay Lights

Washable Dimensions
Length	12500 - 28000 mm
Width	2700 mm
Height	3700, 4300, 4600, 5100 mm
Bay Dimensions
Length	16500 mm
Width	6000 mm
Height	~ 6000 mm
Electricity
Voltage	415 V AC
Phase	3 Phase
Frequency	50 Hz
Generator	Can also run-on Backup Generator System
Connected Load	Can vary from 7.5 hp / 5.7 kW - 60 hp / 44.76 kW depending upon the equipment configuration
Water Supply
Flow rate	200 lpm max
Air Supply
Pressure	7 bars
Connection	12 mm NB
